New products from Aurora at InfoComm Day 2 – Booth 3059
Aurora Newsletter June 18 th 2015
IN THIS ISSUE: DXM-G3, DXP-62 and IPX-TCW3 introduced at InfoComm
V-Tune Pro 4K Awarded Commercial Integrator BEST Award
DXM-G3, DXP-62 and IPX-TCW3 introduced at InfoComm – Booth 3059:
DXM third generation Matrix switchers
New at InfoComm 2015, DXM third generation Matrix switchers, the DXM-88-G3 8×8 matrix, DXM-1616-G3 16×16, and the DXM-3232-G3 32×32 card-cage matrix systems. Updated to 4K UHD these completely new systems add some major features to the system such as embedding Aurora ’ s QXT touch panel control engine as the main interface for the matrix.The front panel will now house the new QXT-700 touch panel offering not only control for the Matrix but full control for the entire system adding IP, RS232, IR, Relays and DIO ports directly to the Matrix. Additional updates include an embedded 1G network switch allowing Ethernet to pass directly over the HDBaseT inputs and outputs for streamlining wiring infrastructure throughout a facility.The DXM-G3 system will also provide PoH (Power over HDBaseT) for all Aurora HDBaseT peripherals (HDBaseT Wall plates and Receivers). The system also adds Audio Breakaway switching giving complete flexibility for multi-zone audio enhancement.
Available in 8×8, 16×16 and 32×32 Configurations
Supports up to 4K UHD Resolutions
Hot-Swappable I/O Cards for Easy Service – Available in HDMI®, HDBaseT, Fiber and HD-SDI
RS232 Over HDBaseT Receivers – No PoE Injector Required
The new DXP-62 high-end low-cost scaler accepts up to four (4) HDMI inputs and two (2) VGA/YPbPr/Composite inputs and scales up to 1920×1200 HD resolution @60Hz via the units HDMI and HDBaseT simultaneous outputs. Leveraging One Room – One Cable™ features, the HDBaseT output will pass PoH power to the awaiting HDBaseT Receiver as well as RS232 and IR control for the display. The unit will be available in packages with any of Aurora ’ s award-winning DXE-CAT receivers allowing the customer to configure with onboard amplification, relay control and background/paging integration for a complete single cable solution. With the addition of four (4) external audio inputs, additional MIC input with independent volume control, de-embedding line level stereo output and auto sensing/switching video inputs, the DXP-62 is perfect for Classrooms, Conference Rooms and AV Cart applications.
Utilizing Aurora ’ s IPBaseT™ technology, which combines various IP/AV standards to work together as one, the IPX-TCW3 Series provides one of the most advanced IP Streaming solutions on the market. It is the industry ’ s first 4K2K IP wall plate with zero compression and latency based on BlueRiver NT™ platform. Using a transmitter (encoder) and receiver (decoder), respectively, used to be the standard – until now. The IPX-TCW3 Series can be set up as either one to make installation, inventory, and troubleshooting easier.
Another industry first is the option slot to add other IP capabilities, like ExtremeUSB® (USB 2.0 over IP) or Dante® audio, for a more complete, distributed system. Audio, video, data, and control can be sent securely to one or many IPX-TCW3 transceiver units using off-the-shelf 10G Fiber or CAT Ethernet switches.
When the IPX-TCW3 is set up to be a transmitter, the 2 HDMI inputs become a source switch and the HDMI output becomes a potential loop out. When set up as a receiver, a user can select the local HDMI inputs or an IP source. Seamless switching of the sources further enhances the presentation. Regardless of how the IPX-TCW3 is set up, the audio can be de-embedded at any location, break away, and/or be sent to or received from a Dante® enabled device. The USB 2.0 option is also flexible, working as a KVM and/or a high-speed data transfer (480Mbps) for memory sticks.
Choice is important. That ’ s why the IPX-TCW3-F has an SFP+ port that can use single or multi-mode fiber and the IPX-TCW3-C can use Category 5e/6/6A – making the IPX-TCW3-F the ultimate AV IP product on the market today.
IPBaseT tranceiver – one unit can be configured as a transmitter (encoder) or receiver (decoder)
4K with zero compression and zero latency
Available for 10G fiber or 10G copper networks
Two HDMI inputs, one HDMI output
128×128 w/HDCP distributed routing (nearly unlimited scalability without HDCP)
Seamless and breakaway switching
Video wall capabilities
Built in control system with web server for display and source control
Dante® IP audio and ExtremeUSB® (USB 2.0 480Mbps) options
Available in surface/rack-mountable (IPX-TC1) or wall plate (IPX-TCW3) versions
